Table 3 summarizes the specifications for each of the PowerEdge T320 features. For the latest

information on supported features for the PowerEdge T320, visit Dell.com.

Feature

PowerEdge T320 technical specification

Form factor

5U rackable tower

Processors

Intel Xeon processor E5-2400 product family

Intel Xeon processor E5-1410

Intel Pentium processor 1400 product family

Processor socket

1 socket

Internal interconnect

Intel DMI 2.0

Cache

2.5MB per core with core options of 2, 4, 6, or 8

Chipset

Intel C600

Memory

Up to 192GB (6 DIMM slots): 2GB/4GB/8GB/16GB/32GB DDR3 up to 1600MT/s

PCIe slots

5 PCIe slots

 1x16 slot with x16 bandwidth, 3.0, full-height, full-length

 1x8 slot with x4 bandwidth, 3.0, full-height, half-length

 1x8 slot with x4 bandwidth, 2.0, full-height, half-length

 1x8 slot with x4 bandwidth, 3.0, full-height, full-length

 1x8 slot with x1 bandwidth, 2.0, full-height, full-length

RAID controller

Internal controllers:

PERC S110 (SW RAID)

PERC H310

PERC H710

PERC H710P

Internal HBAs (non-RAID):

Internal tape adapter

External HBAs (RAID):

PERC H810

External HBAs (non-RAID):

6Gbps SAS HBA

Hard drives

Drive bay options:

4 x 3.5” cabled drive bays or

8 x 3.5” or 2.5” hot-plug drive bays or

16 x 2.5” hot-plug drive bays

Hot-plug hard drive options:

2.5” SATA (7.2K), nearline SAS (7.2K), SAS (15K, 10K), SAS SSD, SATA SSD

3.5” SATA (7.2K), nearline SAS (7.2K), SAS (15K)

Self-encrypting drives available

Cabled hard drive options:

3.5” SATA or SAS

Embedded NIC

Broadcom

5720 1GbE Dual Port LOM

I/O adapter options

1Gb Ethernet:

Broadcom 5720 Dual Port 1Gb Base-T

Broadcom 5719 Quad Port 1Gb Base-T
