Relative humidity

Operating

See Fresh Air for relative humidity information

Storage

5% to 95% at a maximum wet bulb temperature of 33°C (91°F); atmosphere must be

condensing at all times

Maximum vibration

Operating

0.26 Grms at 5Hz to 350Hz in all orientations

Storage

1.87 Grms at 10Hz to 500Hz for 15 minutes (all six sides tested)

Maximum shock

Operating

Half sine shock in all operational orientations of 31G +/– 5% with a pulse duration of 2.6ms

+/– 10%

Storage

Half sine shock on all six sides of 71G +/– 5% with a pulse duration of 2ms +/–10%; square

wave shock on all six sides of 27G with velocity change at 235 in/sec or greater

Altitude

Operating

–15.2m to 3048m (–50 ft to 10,000 ft)

Storage

–15.2m to 12,000m (–50 ft to 39,370 ft)

Airborne contaminant level

Class G1 or lower as defined by ISA-S71.04-1985

The Dell PowerEdge T320 iDRAC7 incorporates an integrated video subsystem. The graphics

controller is the 2D Matrox

G200. The video frame buffer (16MB) is contained within the iDRAC7

RAM (256MB) device.

The T320 system supports the 2D graphics video modes listed in Table 27 and Table 28.

Resolution

Refresh Rate (Hz)

Color Depth (bit)

640 x 480

60, 70

8, 16, 32

800 x 600

60, 75

8, 16, 32

1024 x 768

60, 75

8, 16, 32

1152 x 864

60, 75

8, 16, 32

1280 x 1024

8, 16, 32

Resolution

Refresh Rate (Hz)

Color Depth (bit)

640 x 480

60, 70

8, 16, 32

800 x 600

60, 75

8, 16, 32

1024 x 768

8, 16, 32
