Table 5 lists the various features on the T320. For additional information, see the

Dell PowerEdge

T320 Systems Owner’s Manual

on Support.Dell.com/Manuals.

Feature

Description

Power button

ACPI-compliant power button with an integrated green power LED

Front bezel

Covers the system’s front-loading hard drives and locks for security

NMI button

Used to troubleshoot software and device driver errors; use only if directed

to do so by qualified support personnel or by the operating system's

documentation

System identification button

Buttons on the back and front of a system to help identify the unit in a data

center environment

Hard drives

Up to sixteen 2.5-inch drives

USB connectors

Connects USB devices to the server

Information tag

Slide-out label panel for recording system information

Video connector

Connects a monitor to the server; the tower chassis has one port on the

back of the chassis; the rack chassis has a port on both the front and back of

the chassis

LCD panel and buttons

Displays system ID, status information, and system error messages;

the hot-plug chassis has two navigation buttons to scroll through the menu

on the LCD and one select button

Optical drive

Optional half-height DVD or DVD+RW drive

Power supply units

Supplies power to the server

Power supply indicators

Indicates whether server has power

NIC indicators

Indicates network activity and status

PCIe slots

Connects PCIe expansion cards to the server

Ethernet connectors

Connects integrated 10/100/1000 NICs to the server

Serial connector

Connects a serial device to the server

iDRAC7 Enterprise port

Dedicated management port for optional iDRAC Ports card
